ASTM A213 TP316L Stainless Steel Seamless Cold Rolled Pipe For High Temperature Heat Exchanger Boiler

Brand Name : YUHONG

Model Number : ASTM A312 TP316L

Certification : ISO, SGS, BV, ISO&SGS, ISO/CE/SGS

Place of Origin : CHINA

MOQ : 100 KGS

Price : NEGOTIABLE

Payment Terms : T/T, L/C

Supply Ability : 1500 Tons Per Month

Delivery Time : 20-80 days

Packaging Details : Ply-wooden Case /Iron Case/ Bundle with plastic Cap

Steel grade : 300 Series, Stainless Steel 304/316L, 400 Series, X5CrNi18-20, 200 Series

Type : Seamless Pipe

Standard : ASTM, AISI, DIN, EN, GB, JIS, etc.

Length : Customized

Thickness : Customized

Technique : Cold Rolled Hot Rolled, Cold Drawn, Extrusion, Cold Drawn/Cold Rolling or Both of them

Product name : Stainless Steel Pipe, 304 304L 316 316L 321 310S Stainless Steel Welded/Seamless Tube

Material : Stainless Steel

Outer diameter : 6-630mm, 6-762mm, 6-860mm, customized

Grade : 201/202/304/304L/316/316L/321/321H/347/347H/310S/410/420/430/440/439, etc

Finish : Brush Polish, Cold Drawn, Bright Annealed or Un Annealed

Application : Construction, Industry, etc.

Certificate : ISO, SGS, BV, etc.

Package : Standard Export Package

Size : Customized

Surface Treatment : Polished, Mirror, Brushed, etc.

Contact Now

ASTM A213 TP316L Stainless Steel Seamless Cold Rolled Pipe For High Temperature Heat Exchanger Boiler

Yuhong Special Steel has been engaged in seamless welded steel pipes of austenitic stainless steel and nickel alloy steel (Hastelloy, Monel, Inconel and Inconel) for more than 30 years, and has steel pipes sold every year. more than 80,000 tons. Our customers cover more than 45 countries including Italy, UK, Germany, USA, Canada, Chile, Colombia, Saudi Arabia, South Korea, Poland, Singapore, Australia, France, etc.

Description

Grade 316L is a low carbon version of 316 stainless steel. When cold worked, 316 can produce high yield and tensile strengths similar to duplex grades.
It is commonly used in the chemical and petrochemical industries, food processing, pharmaceutical equipment, medical devices, drinking water, wastewater treatment, marine applications and construction applications close to coasts or urban areas.

These seamless pipes are highly resistant to chloride corrosion, so 316l stainless steel pipes are resistant to pitting and crevice corrosion even in chloride-rich environments. Our stainless steel pipe 316l seamless products can be used in marine, marine applications, sea water purification systems, and wastewater management applications. There are different pipe schedules to accommodate different diameters and wall thicknesses. Stainless Steel Tube 316l Schedule 40 is a medium pressure vessel capacity, while Stainless Steel Tube 316l Schedule 10s has a relatively small wall thickness. Our 316l seamless pipe Schedule 40 pipe is one of the most commonly used pipes in the oil and gas industry. Our resistance welded SS 316l Erw tubes are stronger and last longer. The advantage of 316l welded pipe is that it is easy to weld with or without filler material. We also offer square tube 316l for extra strength in structural applications. Please contact us for a free quote.

Some of the quality tests carried out by our quality department includes:

Corrosion Test Only when specifically requested by the customer
Chemical Analysis Conduct tests according to required quality standards
Destructive / Mechanical Testing Tensile | Hardness | Flattening | Flare | Flange
Reverse-bend and Re. flat tests Fully compliant with relevant standards and ASTM A-450 and A-530 specifications, ensuring trouble-free extension, welding and use on the client side
Eddy Current Testing Done to detect homogeneities in subsurface by using Digital Flaw-mark Testing System
Hydrostatic Testing 100% hydrostatic test, check pipe leaks according to ASTM A 450 specification, the maximum pressure we can support is 20Mpa/7s.
Air Under Pressure Test Check for any signs of air leakage
Visual Inspection After passivation, each tube is subjected to a thorough visual inspection by trained personnel to detect surface defects and other defects


Supplementary Testing : In addition to the above tests, we also carry out supplementary tests on finished products. Tests carried out in this regard include:

  • Eddy Current Testing
  • O.P Testing
  • Radiography Testing
  • Corrosion Testing
  • Micro Testing
  • Macro Testing
  • IGC Testing
  • Ultrasonic testing
  • Liquid Penetrate testing

Chemical composition ¹
C
≤ %		 Si
≤ %		 Mn
≤ %		 P
≤ %		 S
≤ %		 Cr
%		 Mo
%		 Ni
%		 V
0.0 1.00 2.00 0.045 0.030 18.0-20.0 2.00-3.00 10.00-14.00
Nb Ti Al Co Cu
%		 N
≤ %		 Fe
-- -- -- -- -- -- --
¹ in accordance with Key to Steel 2001
